| Electrical Specifications | |
| Frequency Range: | 50-51 MHz or 51-52 MHz |
| Free Space Forward Gain: | 6.8 dBi |
| Front to Back Ratio: | 20 dB |
| 3 dB Beamwidth: | 66° |
| Nominal Input Impedance: | 50 Ohm |
| SWR Across Entire Band: | < 1.2 |
| Maximum Power Input: | 100 W |
| Matching Method: | Direct feed through common mode choke. |
| Connector: | 2 x “N” |
| Mechanical Specifications | |
| Boom length: | 2 m |
| Boom : | 30 x 30 mm |
| Longest element: | 3.1 m |
| No. of elements: | 2 x 3 |
| Element position: | Slant configuration +-45deg |
| Turning radius: | 4.2 m |
| Mounting Mast Diameter: | 5/4″ – 2-3/4″ 43-70 mm |
| Survival Wind Speed: | 150 km/h |
| Packed size length: | 1.47 m |
| Weight: | 5.6 kg |
